Specail Features

• Communicative format between digital load cell and indicator
• Wall mounting type
• 10 keys(including ten keys)
• Installed(Current loop)
• Standard external output(4 contactors)
• 256 group-printing records can be stored
• Applications: Digital truck scale, Digital packer scale, Digital platform scale, Digital hopper scale, etc.

Specifications

GRADE	UNITS
Rated Capacites	kgf	10tf, 25tf, 30tf
Total error Creep for 30minute Temperature zero value shift Temperature output value shift	% % %/10℃ %/10℃	0.02 0.02 0.01 0.02
Excitation Recommended Maximum Power source Power consumption Measuring rate Asynchrone interface Baudrate Display Span calibration Number of bus adresses Maximum transmitting distance Limit load Operating temperature range	V DC V DC V W Times/sec BPS EA m % ℃	9-12 20 AC200~240V, 50Hz Approx. ≤50 50 RS-485 / 5-Wire 9600 VFD 7digit Full digital calibration max.32 1200 150 -30 to +70
